Stainless Steel Wall Slot System
Stainless Steel Wall Slot System
Stainless Steel Wall Slot System
Stainless Steel Wall Slot System
- PPE Plastic / 304 Stainless Steel
- 3.3' (39 Inches) - Length
- A-D Load Class
- Pool Side, Patios, Porches and more
- End Cap Options Available Below
- Trusted by 10,000+ contractors!
Product Details
- Specifications and Downloads
- Product Description
- Installation videos
Specifications and Downloads
Specifications and Downloads
- 4" Internal width stainless steel slot drain system
- 5/8" opening with multiple channel depth options
- 4" Height of slot grate in addition to channel depth
- Install up against wall or existing foundation with offset slot grate
- Excellent for paver, tile, and concrete pour installations
- Used in driveways, pools, patios, and heavy traffic areas
- ADA / Heel Proof cap available as addition for debris protection
- Perfect for high water volume with little surface area coverage
INCLUDED IN PACKAGE
1 - Channel Depth of choice
1 - Heavy Duty Stainless Steel Wall Slot Grating
For more product information please see product description tab above
Product Description
Product Description
Stainless Steel Wall Slot System | A-D Load Class |
Vodaland designed the Stainless Steel Wall Slot System to provide a perfect system that is suitable for any application that goes directly against the wall. A surface level slot drain system that serves such aesthetic and modern finish making it excellent for pool side, patios, porches, and more.
Key Features:
● 304-Grade Stainless Steel - Provides durability and corrosion resistance
● ADA Compliant - Ensures safety for both residential and commercial applications
● A-D Load Class Rated - Can withstand up to 89,000 LBS per EN 1433 (400KN)
● Compatible with any 4” Base Plastic Channel Drain
● Slot Grate Cover - ADA/Heel Proof cover for additional safety and debris protection
Expanded Product Overview:
The Stainless Steel Wall Slot System is an excellent slot drainage system for any application that requires an offset slot grating. It allows you to have an installation against the wall, allowing you to have a modern and low profile finish. A stainless steel slot drain system that offers compatibility with Vodaland’s 4” Channel Drain System. Allowing you to have options for both Pre Slope or Neutral drainage systems.
A durable and chemical resistance system that is made out of 100% 304-Grade Stainless Steel material. Perfect system for both residential and commercial applications that is also ADA compliant (American with Disabilities Act), suitable for pools, patios, walkways, and even driveway projects as it can also withstand up to 89,000 LBS (A-D Load Classification).
Common Application:
● Patios
● Pool
● Porches
● Driveways
● Any Commercial Application
Technical Specifications:
● Material: 304-Grade Stainless Steel Grate
● Channel Length: 3.3 FT (39 Inches)
● Slot Width: 5/8” Internal & 1” External
● Slot Grate Height: 3 ⅞” Inches
● Load Class: A-D Load Classification (per EN 1433)
Technical Resources: Load Class Compliance
Backed by expert engineering and trusted by professionals nationwide, Vodaland delivers reliable, high-performance solutions designed to meet the demands of every project so you can build with confidence.
