All of our 8” Trench Drain Systems have an end to end connection, providing options for long runs and complicated installations. In addition, all of our 8” systems have a built in 90 degree turn already imposed on the channel. Meaning you need no adapters at all to create a 90 degree turn. Multiple grating and load options to fit your load class needs.

  • FAQ's
  • Load Classes
  • Case Studies

Q. How long is each channel?

Each channel is 3.3 ft in length (1 meter) and are designed to connect end to end for a longer run. Or as long as you wish!

Q. Do you have an installation video?

Yes absolutely, we have installation videos on each and every product page for our pre slope systems. Just open that product page and click the video link. They are excellent.

Q. Can you cut the channels if my lengths are not exact?

Yes absolutely. You can cut and then seal on your end cap with no issues if you have to shorten your distance.

Q. Where can I order these?

Not a silly question, but we are the only company in the market to see high end pre slope systems directly online! Just add to cart, and check out, they will arrive in 3-5 business days!

Q. Do you have Auto CAD files for these channels?

A. Yes absolutely, they are on the download list on the product pages.

Our load classes are derived from A to E on our 8” Trench Drain systems.

A Class - 3,300 lbs - for pedestrian use only

B Class - 27,500 lbs - Medium duty traffic and cars. Light trucks and speeds less that 30 mph.

C Class - 55,000 lbs - Heavy duty traffic, forklifts, buses and garages.

D Class - 88,000 lbs - Heavy duty hard tire forklifts, trucks, gas stations, industrial areas

E Class - 132,000 lbs - General dock and aircraft installations.

Here are some great case studies from some customers who utilized our 8" Internal systems.

8" Channel on our driveway.

Trench Drains in Seattle Airport.
