8" Channel Galvanized ADA / HEEL PRO Package
8" Channel Galvanized ADA / HEEL PRO Package
8" Channel Galvanized ADA / HEEL PRO Package
8" Channel Galvanized ADA / HEEL PRO Package
- PPE Plastic / Galvanized Steel
- 3.3' (39 Inches) - Length
- A - Load Class
- Patios, Porches, Parks and more
- End Cap Options Available Below
- Trusted by 10,000+ contractors!
Regular price
$259.00
Regular price
Sale price
$259.00
Unit price
per
free shipping over $999
3-5 days delivered
×
×
Product Details
- Specifications and Downloads
- Product Description
- Installation videos
Specifications and Downloads
Specifications and Downloads
- 8" Internal width galvanized steel ADA package
- Comes with galvanized grate, channel
- Connect multiple channels for longer run
- 4" and 6" PVC or corrugated pipe bottom outlet options
INCLUDED IN PACKAGE
1 Unit - Channel 8" Depth
1 Unit - Stainless Steel Grating
For more product information please see product description tab above
Downloads
PDF
DWG
BIM
Channel Specification Sheet
Grating Specification Sheet
Installation Guide
Supplemental Installation Guide
Product Description
Product Description
8" Channel Galvanized ADA/Heel Pro Package | A - Load Class |
Vodaland designed and manufactured the 8” Galvanized Steel ADA/Heel Pro package to provide a system that can be suitable for both residential and commercial applications. This system is a foot traffic rated perfect for porches, patio, sidewalks, and more.
Key Features:
● PPE Plastic Channel with Galvanized Stamped Steel Grate
● ADA/Heel Proof Complaint Design Grating - Ensures pedestrian accessibility and safety
● A - Load Classification - Suitable for pedestrian applications.
● Modular Outlets - Supports multiple pipe connections options at both ends, on either side, and bottom of the channel.
Expanded Product Overview:
The 8” Galvanized Steel ADA/Heel Pro Package is an A-Load Classification, supporting a foot traffic weight rate making it suitable for quite a number of applications such as gardens, walkways, or porches. It is the ideal grate to use for long runs and complex installations that provide an easy connection with the 8” Channel Drain, and typically paired with the installation grating fasteners for tight lock and security. This system provides multiple outlet location and size options of 4” and 6” pipe connection for water distribution. A trench drain system that is made to be modular and allows you to create a 90 degree turn without needing any adapters making it perfect for all types of layout runs.
Common Application:
● Patios
● Gardens
● Porches
● Walkways
Technical Specifications:
● Material: PPE Plastic Channel with Galvanized Steel Grate
● Channel Length: 3.3 FT (39 Inches)
● Channel Width: 8” Internal & 10.25” External
● Load Class: A Load Rate - 3,300 LBS (Pedestrian Rated)
Vodaland delivers reliable and high performance water solution systems. Backed by expert engineers and trusted by professionals nationwide. Systems that are designed and certified to meet the demands of every project so you can build with confidence.
INCLUDED IN PACKAGE
1 Unit - Channel 8" Depth
1 Unit - Galvanized Steel Grating
