8" Ductile Cast Iron Slotted Grate
8" Ductile Cast Iron Slotted Grate
8" Ductile Cast Iron Slotted Grate
8" Ductile Cast Iron Slotted Grate
- Ductile cast Iron
- 19.7" L x 9.4" W x 1.0" H
- C - Load Class
- Corrosion Resistant
- More Product Information Below
- Trusted by 10,000+ contractors!
Couldn't load pickup availability
FAQ’s
3D Model of our 8" Cast Iron Slotted Grate
Zoom in and out to get a better look at this grating system. You can use AR on your compatible phones to even place on your ground for a nice example of what it will look like in your installation!



Product Details
- Specifications and Downloads
- Product Description
Specifications and Downloads
Specifications and Downloads
- Fits 8" trench drain or channel system
- C Load class of heavy duty load
- Grating fasteners available for grate to channel lock
FEATURES
- Great Original Look
- Installed with grating fasteners for tight lock
- C Class - 55,000 LBS
- Flow Rate: 367 GPM
For more product information please see product description tab above

Product Description
Product Description
8” Ductile Cast Iron Slotted Grate | C - Load Class |
Vodaland designed and manufactured the 8” Ductile Cast Iron Slotted Grate to provide a system that is ideal for heavy-load residential and commercial applications. A high performance and durable system, perfect for vehicle or forklift traffic.
Key Features:
● Ductile Cast Iron Steel Grate - Provides durability and stability in place.
● C - Load Classification - Supporting up to 55,000 LBS.
● Removable Grates - Easy access for maintenance.
Expanded Product Overview:
The 8” Ductile Cast Iron Slotted Grate is a heavy duty load rate system, supporting up to 55,00 LBS of weight and a C-Load Classification (per EN1433). This system is perfect for driveway, garages, factories, parking lots, and more. An excellent system to use for long runs and complex installation that provides a simple connection on Vodaland’s 8” Channel Drain. Pairing with the grating fasteners, this ensures you have a tight and lock security system.
Common Application:
● Driveways
● Garages
● Parking Lots
● Driveways
Technical Specifications:
● Material: Ductile Cast Iron Steel Grate
● Grate Length: 3.3 FT (39 Inches)
● Grate Width: 8” Internal & 9.4” External
● Load Class: C Load Rate - 55,000 LBS (Forklift Rated)
