Easy Custom Curve - Alpha

Easy Custom Curve - Alpha

Regular price $15.00
Regular price Sale price $15.00
Sale Sold out
free shipping over $999
3-5 days delivered
View full details
  • Specifications and Downloads
  • Product Description
  • Installation videos

Specifications and Downloads

Specifications and Downloads

  • 4" Internal trench drain system with plastic grating
  • Snap and lock connections
  • 4" pipe outlet out of the included bottom adapter
  • Pedestrian load rated
  • 90 degree turns anywhere on both sides

INCLUDED IN PACKAGE

1 - Easy Custom Curve - Alpha

For more product information please see product description tab above



Downloads
PDF
DWG
BIM
Easy 2 Specification Sheet
PDF :
DWG :

Product Description

Product Description

This Alpha unit, is the first section in our revolutionary custom curving trench drain. This channel will lock one end to the Beta channels and other end with a standard Easy 2 Channel with a snap connection for easy installation. Gratings snap into place and are easy to remove for cleaning. Channels are 12 inches in length and 5 inches in width. Multiple placement options for 4" outlet out of bottom of channel with the Easy 2 outlet nozzle. Along with optional side cut outs for 90 degree turns. This is for pedestrian and garden use.

For full description please watch the installation video

PARAMETERS

Article ............ 08818-R1

Material ......... PPE Plastic

Dimensions ... 39.5”L x 4.87”W x 2.87” H

Weight ........... 1.4 LBS

Load Class .... A15 - 3,300 LBS

INCLUDED IN PACKAGE

1 - Easy Custom Curve - Alpha

1 - Easy 2 Closed End Cap
