4” Stainless Steel Edgeless Fillable Package – Durable Custom-Fill Drainage System

The 4” Stainless Steel Edgeless Fillable Package is made for a customizable water drainage solution in pedestrian and light traffic areas.

Key Features:
● B Load Class – This system is made for areas with foot traffic or light vehicles
● Pre-sloped – Built in slope, as the run gets longer the channels will continuously get deeper in depth
● ADA Compliant – Built to keep walkways safe and accessible for everyone
Edgeless – Provides a smooth, clean appearance from above
● Customizable – Designed for customizable fill to seamlessly blend with your landscape

Expanded Product Overview:
The Vodaland 4” Stainless Steel Fillable Edgeless Package is rated to Load Class B, making it ideal for pedestrian areas and light-duty vehicular use. Its modern, edgeless design blends seamlessly into any landscape, preserving your aesthetic while delivering reliable drainage performance.

Constructed from durable 304 stainless steel, the fillable grate is designed to be inlaid with gravel, stone, or the aggregate of your choice. The aggregate should be at least 1/4” in size to prevent it from passing through the grate. It must be free of fines and remain permeable to ensure unobstructed stormwater flow. As water flows through the surface, it’s collected by the internal channel and directed away as needed providing both effective drainage and a clean, integrated finish.

This system features an internal slope to promote efficient water flow. Optional 90-degree cutouts allow for flexible layout configurations, making 4” Stainless Steel Fillable Edgeless Package an ideal choice for high-performance drainage with ADA-compliance surface ensures safe access for pedestrians, wheelchairs, and carts, making it a versatile solution for both public and commercial spaces.

Common Applications:
● Walkways
● Pools
● Driveways

Technical Specifications:
● Material: PPE Plastic – 304 Stainless Steel (Grating)
● Dimensions: 39.5” L X 5.8” W
● Load Capacity: B Load Class – 27,500 LBS
● Internal Width: 4”
● Connection Type: Snap and Lock
● Grating Color: 304 Stainless Steel, Aggregate of your choice

Backed by expert engineering and trusted by professionals nationwide, Vodaland delivers reliable, high-performance solutions designed to meet the demands of every project so you can build with confidence.
