22x22 Catch Basin Solid Galvanized Grate Package

22x22 Catch Basin Solid Galvanized Grate Package

Skip to product information
1 of 2
View full details

Product Details

  • Specifications and Downloads
  • Product Description
  • Installation videos

Specifications and Downloads

Specifications and Downloads

  • Vehicle load rated (light)
  • ADA and Heel Proof Compliant
  • Connects to 6", 8",10" and 12" pipe outlets on all four sides

INCLUDED IN PACKAGE

1 - 22x22 Catch Basin

- Galvanized Closed Grate

For more product information please see product description tab above



Downloads
PDF
DWG
BIM
Specification Sheet
PDF :
DWG :
Grate Specification Sheet
PDF :
DWG :
Installation Guide
PDF :

Product Description

Product Description

22x22 Catch Basin Solid Galvanized Grate Package / B-Class

A Catch Basin Package designed to provide a pass through drainage solution in driveways, garages, walkways and more.

Key Features:
A load Class - Supports up to 28,100 lbs per foot
ADA Compliant / Heel Proof- Ensures a safe, trip free surface
Multiple Connection Sizes- Connects to 6,8,10, and 12 inch piping on all 4 sides
Removable Grate

The 22x22 Catch Basin Solid Galvanized Grate Package will allow no water to pass through, with a lift- up handled for simple removal. In addition to 6,8,10, and 12 inch pipe outlet connections, 22x22 Catch Basin Stainless Steel A Class Package is ADA Compliant and Heel Proof. We pride ourselves with our unique grating options and style.

Common Installations:
Driveways
Garages
Walkways

Technical Specifications:
Size- Basin: 22" L x 22" W x 22" H Grate: 21”x21"
Material- PPE Plastic Basin / Galvanized Stamped Steel Grate
Load Class- B-Load Class
Outlet Size- 6,8,10, and 12 inch

Technical Resources: Load Class Compliance
